SSL series Semi-electric Self Loading Lifter
SSL
1. Steering chain auxiliary device.
2. The foot brake, more stable,
3. Sealed batteries free of maintenance safe operation and no pollution.
4. Explosion-proof valve design, down more stable and reliable.
2. The foot brake, more stable,
3. Sealed batteries free of maintenance safe operation and no pollution.
4. Explosion-proof valve design, down more stable and reliable.
Quantity:
Name:SSL series Semi-electric Self Loading Lifter
Features of Self Loading Lifter
1. Self Loading Lifter with Steering chain auxiliary device.
2. Self Loading Lifter with The foot brake, more stable,
3. Self Loading Lifter with Sealed batteries free of maintenance safe operation and less pollution.
4. Self Loading Lifter with Explosion-proof valve design, down more stable and reliable.
| Model | Self Loading Lifter SSL | |
| Rated Capacity | kg | 500 |
| Load Center | mm | 400 |
| Wheel Base | mm | 860 |
| Front Wheel Distance | mm | 380 |
| Rear Track | mm | 670 |
| Min. Fork Height | mm | 90 |
| Max. Fork Height | mm | 1300 |
| Height of Frame (Fork Down) | mm | 1400 |
| The Lifting Height of Whole (After Tape File Shelf) | mm | 2900 |
| Min. Right Angle Channel Width | mm | 1150 |
| Steering Rear Wheel | mm | 100x50 |
| Loading Wheel | mm | 70x60 |
| Guide Wheel | mm | 40x26 |
| Overall Length | mm | 1600 |
| Overall Width | mm | 790 |
| Fork Size | mm | 1150x155x60 |
| Fork Width | mm | 535 |
| Turning Radius | mm | 1120 |
| Lifting Speed | mm/s | 80 |
| Descent Speed | mm/s | 80 |
| Lifting Motor Power | V/Kw | 12/0.8 |
| Battery | V/Ah | 12/33 |
| Type of Driving | Pedestrain | |
| Material of Wheel | Nylon/ PU | |
| Net Weight | kg | 195 |
