DB Economic Hydraulic Pallet Truck

Quantity:

Contact Now

add to cart

Message Content

Country

Phone

Name

Features

1. An economic truck for convenient wide use

2. Durable and Economical,

3. Self-contained hydraulic pallet truck.

4. Heavy-gauge steel channel frame with 3.3mm reinforced tapered steel forks designed for smooth pallet entry and exit.

5. Premium hydraulic pump with spring-loaded, safety loop handle has a three-position fingertip control (raise/lower/neutral) for fast lifting and efficient moving.

Model			DB168	DB20
Lifting Capacity		kg	1680	2000
Lowered Fork Height H1		mm	75	85	75
Max Height of ford H2		mm	190	195	185
Lifting Height h		mm	115	110	110
Lenght of Forks L1		mm	1150	800/900/1070/1100/1150/1220
Width of Fords B1		mm	150x50	160x60
Load Wheel	Single	mm	Ø73x80	Ø80x93	Ø74*93
Load Wheel	Double	mm	Ø73x55	Ø80x70	Ø74*70
Steer Wheel		mm	Ø160x50	Ø200x50	Ø180x50
Overall Dimensions	Length L2	mm	1460	1180/1280/1450/1480/1530/1600
	Width W1	mm	520/550	450/520/550/685
	Height H	mm	1160	1160
Self Weight		kg	51/55	72-85
