ET15MH-F Semi-Electric Li-Battery Power Stainless Steel Pallet Jack
The new ET15MH-F electric pallet truck is suitable for carrying out the practical and safe handling of pallets with a maximum weight of 1500 kg in warehouses, depots and logistics centers. It is simple and practical to use also thanks to its compact size and low weight. The total width of the pallet truck is in fact 540/680 mm equal to the width of the forks. This together with the turning radius of only 1320/1390 mm, allows you to work comfortably even in confined spaces.
1. Features of the ET15MH-F Semi-Electric Li-Battery Power Stainless Steel Pallet Truck
High-performance permanent magnet DC motor simulates the soft process of manual pallet truck acceleration to ensure the safety of workers
Unique patented technology gravity control handle, in line with CE, GB, ANSI operating standards, safe and efficient operation.
Compact and quick-change lithium battery, no maintenance, no need to add acid and liquid, up to 2 years warranty.
Walking upright black technology allows workers to operate vehicles safely and effectively in containers or narrow passages.
| Product Code | ET15MH-F | |||
| Unit of measurement | Metric System | Imperial | ||
| Capacity | kg | 1500 | lbs | 3000 |
| Lowered fork height H2 | mm | 85 | inch | 3.3" |
| Steering wheel *1 A | mm | Ø180x65 | inch | Ø7"X2.6" |
| Fork wheel tandem B | mm | Ø78x70 | inch | Ø3"x2.75" |
| Max. lift height H1 | mm | 200 | inch | 8" |
| Total height H | mm | 1250 | inch | 49" |
| Overall length L2 | mm | 1540/1610 | inch | 60.6"x63.4" |
| Fork length *1 L1 | mm | 1150/1220 | inch | 45"/48" |
| Width overall forks W1 | mm | 540/680 | inch | 21"/27" |
| Single fork width W2 | mm | 165 | inch | 6.5" |
| Travel Speed(Load/unload) | 4/4.5kmh | 2.5/2.8mph | ||
| Load center | mm | 600 | inch | 24" |
| Battery Voltage/Capacity | V/Ah | 24V/20Ah Li-Battery | V/Ah | 24V/20Ah Li-Battery |
| Turning Radius | mm | 1320/1390mm | lbs | 52"/55" |
| Service weight | kg | 125 | lbs | 275 |
