GTWY-2000 Double Mast Aluminum Aerial Work Platform

GTWY-2000

●Suitable for 1-2 person to work upraised with better loading capacity;
●Two masts are descended or ascended synchronously;
●Entire lifting unit with guardrail offers such high intensity and convenient installation and disassembling that it could complete assembling or disassembling through lifting only once;
●Easy maneuvering and with straddle legs similar to that of single mast aerial work platform;
●Conforms to CE;
●Available accessories: mast stand, auxiliary for step use, side-sheer unit;
●Power Supply: Single phase AC as standard;DC or both AC as option.

Quantity:

Contact Now

add to cart

Message Content

Country

Phone

Name

Charactistics:
●Suitable for 1-2 person to work upraised with better loading capacity;
●Two masts are descended or ascended synchronously;
●Entire lifting unit with guardrail offers such high intensity and convenient installation and disassembling that it could complete assembling or disassembling through lifting only once;
●Easy maneuvering and with straddle legs similar to that of single mast aerial work platform;
●Conforms to CE;
●Available accessories: mast stand, auxiliary for step use, side-sheer unit;
●Power Supply: Single phase AC as standard;DC or both AC as option.

Parameter:

型号规格 Model Number			AWP6-2000	AWP8-2000	AWP10-2000	AWP12-2000
平台最大高度Max.Platform Height		mm	6000	8000	10000	12000
工作高度Working Height		mm	7700	9700	11700	13700
底座离地距离Ground Clearance		mm	80
平台额定载荷Lift Rated Capacity		kg	300		250	200
工作平台尺寸Platform Size		mm	1500×600		1620×600	1740×600
撑腿展开尺寸Outspread Size		mm	1950×1850		2130×1980	2550×2500
电源Electrical Source	交流AC	v	220
	直流DC	v	24
免维护电池Anerold battery		v/Ah	2×12/60
充电器Charger		v/A	24V/10A
举升电机Lifting Motor	交流AC	v/kw	220/1.5
	直流DC	v/kw	24/2.0
整机长度Overall Length		mm	1550		1670	1790
整机宽度Overall Width		mm	900
整机高度Overall Height		mm	1950		2070
整机重量Overall Net Weight	交流AC	kg	480	580	680	780
	直流DC	kg	510	610	710	810

Product detail:
