Sinolift NPV series NPV50 heavy duty Hand Pallet Jack

NPV50

The 5000kg Extra Heavy Duty Pallet Truck is a reliable solution for efficiently moving heavy loads in manufacturing, wholesale, construction, and machinery delivery. With its reinforced construction, optimized hydraulic system, and convenient features, it offers exceptional performance and strength in demanding industrial settings.It features reinforced steel and extra heavy duty steel wheels and load rollers so it roll easily over any factory floor, even when loaded to maximum capacity.

Quantity:

Contact Now

add to cart

Message Content

Country

Phone

Name

The 5000kg Extra Heavy Duty Hand Pallet Jack is a reliable solution for efficiently moving heavy loads in manufacturing, wholesale, construction, and machinery delivery. With Hand Pallet Jack reinforced construction, optimized hydraulic system, and convenient features, Hand Pallet Jack offers exceptional performance and strength in demanding industrial settings.Hand Pallet Jack features reinforced steel and extra heavy duty steel wheels and load rollers so Hand Pallet Jack roll easily over any factory floor, even when loaded to maximum capacity.

Product Code	NPV50
Unit of measurement	Metric System		Imperial
Capacity	kg	5000	lbs	11000
Lowered fork height H2	mm	85	inch	3.3"
Steering wheel *1 A	mm	Ø180x65	inch	Ø7"X2.6"
Fork wheel tandem B	mm	Ø78x70	inch	Ø3"x2.75"
Max. lift height H1	mm	205	inch	8"
Total height H	mm	1253	inch	49"
Overall length L2	mm	1544/1614	inch	60"x64"
Fork length *1 L1	mm	1150/1220	inch	45"/48"
Width overall forks W1	mm	540/685	inch	21"/27"
Single fork width W2	mm	165	inch	6.5"
Ground clearance, centre of wheelbase	mm	24	inch	1"
Aisle width for pallets 1000x1200 crossways	mm	1744/1814	inch	68.5"/71.5"
Aisle width for pallets 800x1200 lengthways	mm	1794/1814	inch	70.5"/71.5"
Turning radius	mm	1300/1370	inch	51"/54"
Service weight	kg	103/122	lbs	226/268
