Gasoline Forklift

1.8 Ton LPG and Gasoline Forklift

CPYD18
Quantity:
Contact Now
add to cart
All Products

Boost your productivity

Our SINOLIFT 1.8 ton LPG forklift ergonomically designed and capacious operator compartment, together with a type of operational enhancements, facilitates easier operation, improving comfort and helping to boost productivity.

Operator Friendly Features Include:

Spacious Operator Compartment

Capacious operator leg room, inclinable steering column and ergonomically located operator footplates result in an ergonomic design to keep the operator comfortable at all times.

Integrated Instrument Panel

The integrated instrument panel provides critical information promptly. Fuel, oil pressure, temperature, seat belt and hour usage are clearly indicated so that the forklift keeps the operator fully aware of vehicle performance.

Operator Sensing System

After the operator leaves the seat three seconds, the 1.8 ton LPG forklift will stop moving forward and backward immediately, and it will also stop loading and unloading of goods.

Rear Grab Handle with Horn(Optional) and Blue light(Optional)

The horn is in order to alert ambient crew without the need to look away from the direction of

travel. The Blue spot light is an warning system for the 1.8 ton LPG forklift trucks, which ensures greater safety in aisles and especially in confusing crossing areas.

Easy to Service, Efficient To Run

Integrated Electric Components

The central electric control box is located next ti the battery to facilitate easy maintenance.

Easy to Service

The footplate is very easy to remove which gives engineers quick and easy access to service the forklift.

High Powered, Fuel Efficient Performance

GCT K21

Rated output: 31.2KW

R.p.m.: 2250

Rated torque: 143.7N.m

R.p.m.: 1600

Number of cylinder: four

Bore*stroke: 89mm*83mm

Displacement: 2065 cc

Fuel tank capacity: 45 Litre

A Distinguishing Feature of Wear and Dependability

SINOLIFT's goal is to make your material handling operation more efficient and more safe

by minimizing your forklift maintenance downtime to reduce overall maintenance cost.

Power reversal transmission

The top installed control valve:

Accurately adjusts clutch oil pressure

Provides oilily forward / reverse direction changes

Ranges transmission life

Hydrostatic steering system

Fully hydrostatic steering

Self- aligning taper roller bearings

Designed to operate in polluted circumstances and high impact applications

Faster response

Increased Cooling Capacity

Aluminium plate-fin radiator provides excellent cooling capacity with improved air flow.

Hot Tags: 1.8 ton LPG forklift, suppliers, manufacturers, factory, customized, in stock, made in China


ModelCPYD18
1Power TypeGasoline/LPG
2Rated Capacitykg1800
3Load Centremm500
4Lift Heightmm3000
5Fork Size (L×W×T )mm920×120×35
6Mast Tilt Angle (F/R)Deg6°/12°
7Front Overhang (Wheel center to fork face)mm410
8Ground Clearance(Bottom of mast)mm110
9Turning Radius (outside)mm2055
10Min. Intersecting aisle2150
11Max.Gradeability (No load/Full load)%20
12Wheelbasemm1400
13Service weightkg3030
14Battery (Voltage/Capacity)V/Ah12/80
15Overall DimensionLength to face of fork(Without fork)mm2285
16Overall Widthmm1086
17Mast Lowered Heightmm1995
18Mast Extended Height(With backrest)mm3940
19Overhead Guard Heightmm2040
20SpeedTravel (No load)km/h15
21Lifting(Full load)mm/s440
22TireFrontmm6.50-10-10PR
23Rearmm5.00-8-10PR
24EngineModelK21
25ManufactureNISSAN GCT
26Rated output/r.p.m.kw31.2/2250
27Rated torque/r.p.m.N·m143.7/1600
28No.of Cylinder4
29Bore×Strokemm89×83
30Displacementcc2065
31Fuel Tank CapacityL45
32TransmissionTypePowershift Hydraulic
33Stage FWD/RVSJanuary 1
34Operating Pressure for AttachmentMpa14.5
